Non Soda 300BPH 2L Mineral Water Filling Line with high accuracy

Name: Non Soda 300BPH 2L Mineral Water Filling Line with high accuracy
Brand: FillPack
Price: 12000 USD

Quality Non Soda 300BPH 2L Mineral Water Filling Line with high accuracy for sale

Brand Name : FillPack

Model Number : CGF8-8-3

Certification : CE / ISO9001 - 2008

Place of Origin : Zhangjiagang, China

MOQ : 1 set

Price : 12000-30000USD

Payment Terms : TT & L/C

Supply Ability : 20 Sets Per Months

Delivery Time : 30 Working Days After Deposit

Packaging Details : Wooden Case Package

Condition : New

Application : PET bottle water

Automation : Automatic

Suitable Bottle Size : 0.3-2L PET Bottle

Fuction : washing filling capping monoblock

Capacity : 300BPH

Warranty : 1 Year for Spare Parts

Service : Technician avaliable overseas

Contact Now

Fully automatic small 0-2L bottle water filling / bottling machine / equipment / device / unit

The equipment is used in production of non-soda drink of hot juice or cold water packed in polyester bottles. Washing, filling and capping are integrated in one machine. The most advanced technology from Japan and Germany is employed in the design. The gravity fixed liquid surface filling is used. The filling is fast, the amount of liquid is accurately controlled and the dropping and leakage are avoided. Spring cramps are used in the bottle washing process. The empty bottles can be turned over 180~ along the conveying rail. There are two times of internal and external washing, the efficiency of bottle washing is high. The filling by spring type liquid lever controlling filling valve, no dripping. The liquid lever is easy to control. All construction made of SUS304, There is no dead corner inside filling valve. The magnetic torque is used for screw capping. The power of screw capping can be adjusted without steps. The power of the screw capping can also be fixed, and the caps will not be damaged, the capping is reliable. There is electrical heating cold-heat tank enclosed in the whole system especially for keeping hot filling temp during hot juice filling. And it can also be stopping heating by easy electrical break down for cold water filling. It do not need extra steam system to work together. The whole machine is controlled by PLC with touch-screen as the human-machine interface. The amount
 of the drinks in the storage tank can be controlled automatically. The filling and capping will be stopped automatically when there is no bottle. When bottles are cramped wrongly or when caps are not available, the machine can be stopped automatically. The frequency changing technology is used to adjust the operation speed sleeplessly. The production capacity can be displayed digitally and can be adjusted conveniently.

Non Soda 300BPH 2L Mineral Water Filling Line with high accuracy

Model		CGF 8-8-3
Capacity(B/H)(500ml)		2000-3000
Bottle size		Neck:φ20-50mm；Height:150-320mm
Water pressure		0.18-0.25Mpa
Water consumption(kg/h)		1000
Washing station		2
Dripping station		2
Filling precision		＜+1MM
Air pressure		0.4Mpa
Air consumption (m³/min)		0.3
Power(kw)		4
Weight(kg)		1500
Dimension(LWH)(mm)		18001500 2300

Product Tags:

2L mineral water filling line

300BPH mineral water filling line

300BPH pure water production line

Non Soda 300BPH 2L Mineral Water Filling Line with high accuracy Images
